Innovative Technical Solutions
Enhancing Reliability & Efficiency with Advanced Thermal Management and Electrical Solutions
Download Brochure
Product Overview
Key Advantages
✅ Airflow and Cooling Efficiency
—New Technology and Optimized Blade Design
✅ Quiet and Power-Efficient
– Specially designed motor for quiet operation and low power consumption
✅ Long Life and Durability
– Ball bearing construction with a lifespan exceeding 50,000 hours
✅ Size and Voltage Options
– Available in AC 220V/110V and DC 24V/12V
✅ IP65 Dust and Water-Resistant Models
– Suitable for harsh industrial environments
✅ Certified Quality Assurance
– Our products undergo rigorous testing in our in-house UL-certified laboratory
Product Catagories
wdt_ID wdt_created_by wdt_created_at wdt_last_edited_by wdt_last_edited_at Model Order number Bearing Rated voltage Air flow m³/h Dimension mm
1
F2E-80B-230
2018.001
Ball
230V AC
30/36
80*80*38
2
F2E-80B-230-B
2018.070
Ball
230V AC
60
80*80*38.5
3
F2E-80B-115
2018.002
Ball
115V AC
30/36
80*80*38
4
F2E-80B-24
2018.036
Ball
24V DC
64
80*80*24
5
F2E-92S-230
2018.003
Sleeve
230V AC
45
92*92*25
6
F2E-90B-230-B
2018.071
Ball
230V AC
90.5
90.5*90.5*39
7
F2E-92S-115
2018.005
Sleeve
115V AC
45
92*92*25
8
F2E-92S-24
2018.029
Sleeve
24V DC
93
92*92*25
9
F2E-92B-230
2018.005
Ball
230V AC
45
92*92*25
10
F2E-92B-115
2018.006
Ball
115V AC
45
92*92*25
Applications
Used in various fields to keep machines running smoothly:
🏭 Industrial control panels – Prevent electrical enclosures from overheating
📡 Telecommunications equipment – Ensure stable performance of network equipment
🔋 Batteries and energy storage systems – Provide temperature regulation for battery cabinets
🌡️ HVAC and ventilation systems – Improve airflow in cooling systems
🚊 Railway and automotive electronics – Protect control systems from overheating
🏢 Data centers – Air cooling systems ensure data runs in perfect condition
Basic Knowledge
🔍What is an axial flow fan? How does it work?
Axial flow fans cool housings and systems and are designed to operate with a rotating impeller to provide airflow parallel to the fan axis.
📏Choosing the Right Axial Flow Fan?
Consider the following factors:
Airflow (measured in CFM or m³/h) – Ensures adequate cooling performance
Voltage and power consumption – Meet system specifications
Size and mounting options – Installation space and design
IP rating – Meets water and dust protection needs
Outer rotor motors vs. shaded pole motors
📌 Shaded pole motors
✔ Simple and cost-effective
✔ Low starting torque
✔ Lower efficiency, higher energy consumption
Other (mostly found in small cooling fans, household appliances)
📌 Outer rotor motors
✔ More efficient, reduces airflow
✔ Must be compact and have an internal impeller
✔ Reduced noise and vibration
✔ Ideal for industrial and HVAC cooling, as well as high-performance applications
💡 Which to choose?
Cost-sensitive, low-power applications → Shaded-pole motor
For applications involving moving sheet metal, choose an outer rotor motor.
Why Choose Leipole?
As a professional buyer, do you face these challenges?
Delivery delays – affecting project progress and production line stability
Poor technical adaptability – standard products cannot meet complex working conditions
High hidden costs – frequent maintenance, excessive energy consumption, slow after-sales response
Compliance risks – lack of international certification leads to customs clearance and warranty disputes
Leipole is proud to offer one-stop solution:
Global layout, zero delivery delays
Deep customization capabilities to solve complex needs
Worry-free compliance, global access
Cost optimization throughout the entire life cycle
Customization Process
Professional engineers deeply understand your equipment parameters, application environment, and special requirements.
R&D teams develop optimal heat dissipation solutions based on your needs, including airflow calculations and installation planning.
Provide samples for real-environment testing, collect data feedback, and ensure solution effectiveness.
After confirming the solution, production follows strict ISO9001 quality management systems to ensure batch stability.
FAQ
🔹 Q1: What is the service life of Leipole axial fans?
💡 A: Our ball bearing axial fans have a service life of up to 50,000 hours, while sleeve bearing fans have a service life of approximately 30,000 hours.
🔹 Q2: Do these fans operate in high-temperature enclosures?
💡 Q: Yes, do Leipole axial fans operate in temperatures between -10°C and 70°C?
🔹 Q3: Do you offer products with custom brands, different voltages, or airflow requirements? Do you do OEM/ODM?
💡 A: Yes. If our customers have any special requirements, we will tailor-make products for them.
🔹What are axial fans used for?
💡Axial fans are designed to flow air in a straight line parallel to the fan’s axis. They are commonly used for ventilation, cooling, and exhaust in industrial cabinets, electrical enclosures, HVAC systems, and mechanical equipment. They efficiently move large volumes of air, making them ideal for maintaining proper airflow and preventing overheating.
🔹What is the difference between AC and DC axial fans?
💡AC axial fans operate on AC power and are typically used in industrial environments with a constant voltage supply. DC axial fans, on the other hand, operate on DC power and are better suited for applications requiring compact size, precise speed control, and energy savings. AC fans generally offer higher power, while DC fans operate more quietly and have a longer lifespan in low-voltage environments.
🔹Why choose an industrial axial fan?
💡Industrial axial fans are designed for operation in harsh environments such as manufacturing facilities, control panels, and automation systems. These fans offer high airflow, durability, thermal stability, and resistance to dust and moisture. Choosing an industrial-grade fan ensures reliable cooling and extends the lifespan of sensitive equipment.
🔹What are the applications for 250mm axial fans?
250mm axial-flow fans are ideal for medium-to-large electrical cabinets, control cabinets, and cooling systems requiring high airflow. Their larger size makes them ideal for ventilation of industrial machinery, server racks, and heat-generating equipment. The 250mm size combines powerful cooling performance with low noise, making it a top choice for space-intensive equipment.
