Enclosure fan heaters
ENGINEERING SUPPORT
Find the right fit.
Talk to our team about product selection and your application.
Contact technical supportOverview
Key advantages
Forced convection heating – more uniform heat dissipation compared to baseboard heater enclosure
Highly effective anti-condensation – suitable for anti condensation heater for panel and anti condensation heater for motor
Multiple voltage options – 24V enclosure heater, 480V enclosure heater, enclosure heaters 120V
Intelligent temperature control – Enclosure heater with thermostat, automatic temperature adjustment
High safety – high protection level, suitable for heat pump enclosure
Models & specifications
Fan with heater JRQ250/400
Operating voltage: 230VAC 50/60 Hz
Heating element: PTC
Airflow: 45m³/h (50Hz), 54m³/h (60Hz)
Flame retardant rating: UL94 V0
Case material: PPS GS-FR
| wdt_ID | wdt_created_by | wdt_created_at | wdt_last_edited_by | wdt_last_edited_at | Model | Order number | Heat load (W) | Dimension (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 37 | w3381121 | 17/01/2025 09:29 AM | w3381121 | 17/01/2025 09:29 AM | JRQ250 | 2020.008 | 230-270 | 103*103*202 | 1.5 |
| 38 | JRQ400 | 2020.009 | 380-420 | 103*103*202 | 1.5 |

Electrical cabinet heaters with fan JRQFS200/400
Operating voltage: 230VAC 50/60 Hz
Heating element: PTC
Weight: 0.35kg
Leakage current: Max 0.05mA
Case material: PPS GS-FR
| wdt_ID | wdt_created_by | wdt_created_at | wdt_last_edited_by | wdt_last_edited_at | Model | Order number | Operating voltage | Heat load (W) | Max current | Airflow (m³) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 41 | JRQFS200 | 2020.022 | 220-240VAC 50/60Hz | 185-210W | 1.1A | 63m3/h | 0.35 | ||||
| 42 | JRQFS400 | 2020.021 | 220-240VAC 50/60Hz | 386-415W | 2.0A | 63m3/h | 0.35 |
Fan with heater JRQFM100BA-400BA
Heating element: cast aluminum heater
Flame retardant rating: UL94 V0
Case material: aluminum
IP rating: IP20
| wdt_ID | wdt_created_by | wdt_created_at | wdt_last_edited_by | wdt_last_edited_at | Model | Order number | Heat load (W) | Fuse 230VAC/120VAC | Dimension (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
| 37 | w3381121 | 17/01/2025 09:29 AM | Kiva | 02/12/2025 08:59 AM | JRQFM100BA | 2020.010 | 100 | 1/1.4A | 80×112×22 | 0.4 kg |
| 38 | JRQFM150BA | 2020.011 | 150 | 1.25/2A | 80×112×22 | 0.4 kg | ||||
| 39 | JRQFM200BA | 2020.012 | 200 | 1.4/2.5A | 119×151×22 | 0.5 kg | ||||
| 40 | JRQFM300BA | 2020.013 | 300 | 2/4A | 119×151×22 | 0.5 kg |
Anti condensation heater for panel JRQFM300BAP
Order code: 2020.024
Heat load: 300W
Rated voltage: 230V AC 50/60Hz
Power capacity: 285W
Weight: 1250g
Air flow: 95m³/h
Case material: Aluminum
Installation: M6 Screw fixation or clip for 35mm DlN rail
All 4 model pages
Applications
Industrial control cabinet & low voltage switch cabinet – Suitable for electrical cabinet heaters
New Energy & EV Charging Stations – Prevent battery condensation and increase lifespan
Data Center & Commercial Cabinets – Ensure heated enclosure operates stably in low temperature environments
Basic knowledge
What is Enclosure Fan Heater?
Enclosure Fan Heater combines heating element + forced fan convection to heat air and distribute it evenly. Compared with static heater, fan heater can heat up quickly, reduce temperature difference and improve thermal efficiency.
How to choose the right Enclosure Fan Heater?
● Air volume & heating power – make sure to match enclosure heaters 120V or 24V enclosure heater
● Mounting method – suitable for baseboard heater enclosure, easy to integrate into electrical cabinet system
● Protection level – whether it is suitable for humid or high dust environment (such as heat pump enclosure)
Frequently asked questions
Q1: How do I choose the right wattage for an enclosure fan heater?
A
: Calculate the enclosure’s heat load (from electronics), ambient temperature range, and desired internal temperature (typically 10-40°C). Use a heat loss calculator or consult manufacturer guidelines. For example, a 1m³ enclosure in a -10°C environment may need a 200-400W heater. Always factor in air circulation needs—axial fans for small enclosures, crossflow blowers for larger ones.
Q2: What’s the difference between PTC and traditional resistance heaters?
A
: PTC heaters self-regulate, reducing power as temperature rises, which enhances safety and longevity. Resistance heaters are cheaper but prone to overheating, especially in confined enclosures. PTC is ideal for critical applications like energy storage or wind farms.
Q3: Can fan heaters be used in hazardous locations?
A
: Yes, but they must meet standards like NEMA 7 or ATEX. Specify the Class, Division, and Gas Group when ordering. For example, a NEMA 4/7 enclosure with a thermostat is suitable for chemical plants. Always verify with the manufacturer.
Q4: How often should enclosure fan heaters be maintained?
A
: Inspect annually for dust buildup, fan functionality, and thermostat accuracy. In harsh environments (e.g., recycling plants), check filters quarterly to prevent clogging, which can reduce efficiency by 30%.
Q5: Are fan heaters energy-efficient?
A
: Modern low-inrush-current heaters (e.g., 10-65W) and PTC models are more efficient, reducing startup spikes by up to 50%. Pairing with programmable thermostats further optimizes energy use, critical for green industries.
Q6: Why do some heaters fail prematurely?
A
: Common causes include undersizing, poor material selection (e.g., using steel in corrosive environments), or inadequate air circulation. For example, a small enclosure without a fan may overheat, degrading the heater’s epoxy seal.
How does an enclosure fan heater with adjustable thermostat improve temperature control?
An enclosure fan heater with adjustable thermostat maintains precise internal temperatures by cycling the fan heater on/off around your setpoint, preventing both overheating and condensation.
Why choose a compact enclosure fan heater for small control cabinets?
Compact enclosure fan heaters deliver targeted heat and airflow in tight spaces, ensuring uniform temperature without consuming valuable cabinet real estate.
Can I install a DIN rail mount enclosure fan heater in my panel?
Yes. DIN rail mount enclosure fan heaters clip directly onto standard 35 mm rails, simplifying installation and allowing easy replacement or expansion.
Are IP54 rated fan heaters suitable for outdoor enclosures?
Absolutely. IP54 enclosure fan heaters resist dust and splashing water, making them ideal for outdoor or wash-down environments where protection is critical.
What advantages do dual-function fan and heater units offer for electrical cabinets?
Dual-function fan and heater units combine cooling airflow with heat output—automatically switching between modes to maintain optimal cabinet conditions in varying ambient temperatures.
Product inquiry
Related products
Related products
-

LEIPOLE JRQ400 PTC Fan Heater, 400W, IP20, DIN Rail Mount, Anti-Condensation
View item -

LEIPOLE JRQ250 PTC Fan Heater, 250W, IP20, DIN Rail Mount, Anti-Condensation
View item -

Premium JRQFS800BAT 760-840W Enclosure Heater with Integrated Thermostat and High-Flow Axial Fan
View item -

JRQFM200BA: 200W Cast Aluminum Enclosure Fan Heater, DIN Rail Mount
View item
Selection & support
Selecting LEIPOLE enclosure fan heaters
Use forced-air heating when a cabinet needs fast, even heat.
When should I choose a fan heater instead of a plain PTC heater?
A fan heater blows air across its heating element, so it warms the whole cabinet faster and more evenly than a heater that relies on natural convection. The JRQ250/400, for example, combines a PTC element with a 45 m³/h fan at 230 V AC.
Compare PTC heaters →Which models are in the LEIPOLE enclosure fan heater range?
The range covers 100 to 420 W at 230 V AC: JRQ250 and JRQ400 (230–270 and 380–420 W), JRQFS200 and JRQFS400 (185–210 and 386–415 W), JRQFM100BA, JRQFM150BA, JRQFM200BA and JRQFM300BA (100 to 300 W) and the 300 W JRQFM300BAP.
Compare all enclosure heaters →
