Enclosure Top Ventilator
ENGINEERING SUPPORT
Find the right fit.
Talk to our team about product selection and your application.
Contact technical supportOverview
Models & specifications
| wdt_ID | wdt_created_by | wdt_created_at | wdt_last_edited_by | wdt_last_edited_at | Model | motor model | Rated voltage | Air flow m³/h | Rated current(A) | Power (W) | noise level (dB) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 48 | Kiva | 15/07/2025 06:12 AM | Kiva | 15/07/2025 06:12 AM | F2E190-230-DP | M2E09201-AF | 230/50/60 | 570/620 | 0.33/0.32 | 69/73 | 62/64 |
| 53 | Kiva | 15/07/2025 06:16 AM | Kiva | 15/07/2025 06:16 AM | F2E220-230-DP | M2E09202-AF | 230/50/60 | 860/900 | 0.51/0.55 | 105/123 | 73/74 |
| 54 | Kiva | 15/07/2025 06:17 AM | Kiva | 15/07/2025 06:17 AM | F2E225-230-DP | M2E09203-AF | 230/50/60 | 1200/1340 | 0.60/0.74 | 131/165 | 69/71 |
| wdt_ID | wdt_created_by | wdt_created_at | wdt_last_edited_by | wdt_last_edited_at | Model | Size (WxHxL mm) | Rated voltage | Air flow m³/h | Rated current(A) | Power (W) | noise level (dB) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 48 | Kiva | 15/07/2025 06:12 AM | Kiva | 16/07/2025 07:47 AM | F2E190-230-DVP | 400x135x400 | 230AC-50/60 | 570/620 | 0.33/0.32 | 69/73 | 71 |
| 53 | Kiva | 15/07/2025 06:16 AM | Kiva | 16/07/2025 07:48 AM | F2E220-230-DVP | 400x135x400 | 230AC-50/60 | 860/900 | 0.51/0.55 | 105/123 | 74 |
| 54 | Kiva | 15/07/2025 06:17 AM | Kiva | 16/07/2025 07:50 AM | F2E225-115-DVP | 400x135x400 | 115AC-50/60 | 1200/1340 | 1.30/1.45 | 130/171 | 71 |
| 55 | Kiva | 16/07/2025 07:51 AM | Kiva | 16/07/2025 07:51 AM | F2E225-230-DVP | 400x135x400 | 230AC-50/60 | 860/900 | 0.60/0.74 | 131/165 | 71 |
| 56 | Kiva | 16/07/2025 07:51 AM | Kiva | 16/07/2025 07:51 AM | F2E225-380-DVP | 400x135x400 | 380AC.1.-50/60 | 860/900 | 0.34/0.45 | 130/171 | 71 |
| wdt_ID | wdt_created_by | wdt_created_at | wdt_last_edited_by | wdt_last_edited_at | Model | motor model | Rated voltage | Air flow m³/h | Rated current(A) | Power (W) | noise level (dB) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 48 | Kiva | 15/07/2025 06:12 AM | Kiva | 21/11/2025 03:30 AM | F2E190-230-DSP | M2E09201-AF | 230/50/60 | 570/620 | 0.33/0.32 | 69/73 | 62/64 |
| 53 | Kiva | 15/07/2025 06:16 AM | Kiva | 21/11/2025 03:31 AM | F2E220-230-DSP | M2E09202-AF | 230/50/60 | 860/900 | 0.51/0.55 | 105/123 | 73/74 |
| 54 | Kiva | 15/07/2025 06:17 AM | Kiva | 21/11/2025 03:31 AM | F2E225-230-DSP | M2E09203-AF | 230/50/60 | 1200/1340 | 0.60/0.74 | 131/165 | 69/71 |
