LEIPOLE JPTTB 4-PV/JPTTB 4-PV-BU Feed-through Terminal Block 32A 800V Industrial Wiring
LEIPOLE JPTTB 4-PV/JPTTB 4-PV-BU double-level 4-conductor feed-through terminal blocks with screw connection, 32A/800V rating, 0.5–6mm² wire range, UL94 V0 flame retardant, IEC 60947-7-1 compliant, fits standard DIN rails for industrial control and PV power distribution.
- Part number: JPTTB 4-PV/JPTTB 4-PV-BU
- Order code: 1012.084/1012.085
Product Overview
LEIPOLE JPTTB 4-PV and JPTTB 4-PV-BU are double-level 4-conductor screw-type feed-through terminal blocks for standard DIN rail mounting. Designed for industrial control, power distribution and PV-related wiring applications, they provide stable multi-wire connections with reliable screw clamping. Insulation and conductive parts meet industrial standards for safe and consistent performance in industrial working environments.
Key Features & Advantages
Double-level 4-conductor design for high-density wiring
Screw connection for stable and reliable wiring
UL 94 V0 flame-retardant housing for operational safety
Compliant with IEC 60947-7-1 international standards
Compatible with NS 35/7.5, NS 35/15 and NS 32 DIN rails
Space-saving structure for compact cabinet layout
Rated 32A/800V for stable electrical performance
Typical Applications
High-density wiring in industrial control cabinets
Multi-circuit connection in automation systems
Internal wiring of electrical panels and distribution boxes
Wiring for photovoltaic power distribution equipment
Compact wiring solutions for industrial and renewable energy facilities
| Model | JPTTB 4-PV/JPTTB 4-PV-BU |
| Certification | CE, CQC |
| Flammability Class | UL 94 V0 |
| Connection Standard | IEC 60947-7-1 |
| Zack Strip | ZB6 |
| Order Number | 1012.084/1012.085 |
| Size | T6.2×H78.7×W48.7 |
| Rated Current/Rated Voltage | 32A/800V |
| Cross Section | 0.5~6mm² |
| Din Rail Type | NS 35/7.5, NS 35/15, NS 32 |
