LEIPOLE JPT 2.5-PE ground terminal block, screw connection, DIN rail mount, industrial earthing part

LEIPOLE JPT 2.5-PE Ground Terminal Block Industrial Earthing DIN Rail

Name: LEIPOLE JPT 2.5-PE Ground Terminal Block Industrial Earthing DIN Rail
Brand: LEIPOLE
Availability: InStock

Request a quote WhatsApp us

LEIPOLE JPT 2.5-PE ground terminal block with screw connection, UL 94 V0 flammability class, IEC 60947-7-2 compliant, 0.5–4mm² wire range, fits NS 35 series DIN rails for industrial protective earthing.

Add to cart

Product Overview

LEIPOLE JPT 2.5-PE is a ground terminal block for standard DIN rail mounting. It is used for protective earthing in industrial electrical wiring systems. The product uses screw connection and meets industrial standards for stable and safe earthing connection.

Key Features & Advantages

Screw connection type for reliable wiring

Flammability class UL 94 V0

Compliant with IEC 60947-7-2 standard

Compatible with NS 35/7.5, NS 35/15, NS 32 DIN rails

Suitable for 0.5–4mm² wire cross-section

Typical Applications

Protective earthing in industrial control cabinets

Earthing wiring for electrical distribution boxes

Grounding connection for automation equipment

Protective earthing in low-voltage electrical systems

Industrial cabinet grounding wiring

Product Attribute	Value
JPT 2.5-PE Parameters
Model	JPT 2.5-PE
Certification	CE
Flammability Class	UL 94 V0
Connection Standard	IEC 60947-7-1
Zack Strip	ZB5
Order Number	1012.058
Size	T5.2×H58×W38
Cross Section	0.5~4mm²
Din Rail Type	NS 35/7.5, NS 35/15, NS 32
