LEIPOLE JPTTB 4-PE double-layer grounding terminal block, screw connection, DIN rail mounted, industrial protective earthing part

LEIPOLE JPTTB 4-PE Double Layer Ground Terminal Block DIN Rail Industrial Earthing

LEIPOLE JPTTB 4-PE double-layer earthing terminal block features solid screw connection, UL 94 V0 flame retardant performance and IEC 60947-7-2 standard compliance. It supports 0.5–6mm² wire access and matches multiple DIN rail specifications, providing high-density, stable protective earthing for industrial electrical systems.

  • Part number: JPTTB 4-PE
  • Order code: 1012.086
Add to cart

Product Overview

LEIPOLE JPTTB 4-PE is a double-layer protective earthing terminal block designed for standard DIN rail mounting. It is applied to high-density grounding wiring of industrial low-voltage electrical equipment. Equipped with stable screw connection structure, it ensures firm wire fixation and continuous reliable earthing. Premium insulating materials and standardized manufacturing meet industrial safety requirements, adapting to long-term stable operation in various harsh industrial scenarios.

Key Features & Advantages

Double-layer integrated structure for high-density centralized earthing wiring

Screw connection type for firm wire clamping and durable grounding connection

Flammability class UL 94 V0 to strengthen fire resistance and electrical safety

Compliant with IEC 60947-7-2 standard for industrial protective earthing

Compatible with NS 35/7.5, NS 35/15, NS 32 DIN rails for flexible installation

Suitable for 0.5–6mm² wire cross-section to cover conventional grounding cables

Typical Applications

High-density protective earthing for double-loop circuits in control cabinets

Grounding wiring for electrical panels and low-voltage distribution facilities

Safety earthing protection for industrial automation and mechanical equipment

Integrated grounding design for factory low-voltage electrical systems

Space-saving protective earthing solution for compact electrical cabinets

Product Attribute Value
JPTTB 4-PE Parameters
Model JPTTB 4-PE
Certification CE
Flammability Class UL 94 V0
Connection Standard IEC 60947-7-1
Zack Strip ZB6
Order Number 1012.086
Size T6.2×H83.6×W48.7
Cross Section 0.5~6mm²
Din Rail Type NS 35/7.5, NS 35/15, NS 32
