LEIPOLE JPTTB 4/JPTTB 4-BU Feed-through Terminal Block 32A 800V Industrial Wiring
LEIPOLE JPTTB 4/JPTTB 4-BU double-level 4-conductor feed-through terminal blocks with screw connection, 32A/800V rating, 0.5–6mm² wire range, UL94 V0 flame retardant, IEC 60947-7-1 compliant, fits standard DIN rails for industrial control and power distribution.
- Part number: JPTTB 4/JPTTB 4-BU
- Order code: 1012.082/1012.083
Product Overview
LEIPOLE JPTTB 4 and JPTTB 4-BU are double-level 4-conductor screw-type feed-through terminal blocks for standard DIN rail mounting. Designed for industrial control and low-voltage distribution wiring, they provide stable multi-wire connections with reliable screw clamping. Insulation and conductive parts meet industrial standards for safe and consistent performance in industrial working environments.
Key Features & Advantages
Double-level 4-conductor design for high-density wiring
Screw connection for stable and reliable wiring
UL 94 V0 flame-retardant housing for operational safety
Compliant with IEC 60947-7-1 international standards
Compatible with NS 35/7.5, NS 35/15 and NS 32 DIN rails
Space-saving structure for compact cabinet layout
Rated 32A/800V for stable electrical performance
Typical Applications
High-density wiring in industrial control cabinets
Multi-circuit connection in automation systems
Internal wiring of electrical panels and distribution boxes
Power distribution wiring for mechanical equipment
Compact wiring solutions for industrial electrical facilities
| Model | JPTTB 4/JPTTB 4-BU |
| Certification | CE, CQC |
| Flammability Class | UL 94 V0 |
| Connection Standard | IEC 60947-7-1 |
| Zack Strip | ZB6 |
| Order Number | 1012.082/1012.083 |
| Size | T6.2×H83.6×W48.7 |
| Rated Current/Rated Voltage | 32A/800V |
| Cross Section | 0.5~6mm² |
| Din Rail Type | NS 35/7.5, NS 35/15, NS 32 |
