LEIPOLE JPT 4-QU/JPT 4-QU-BU Feed-through Terminal Block 38A 800V Industrial Wiring
LEIPOLE JPT 4-QU/JPT 4-QU-BU 4-conductor feed-through terminal blocks with screw connection, 38A/800V rating, 0.5–6mm² wire range, UL94 V0 flame retardant housing, IEC 60947-7-1 compliant, fits standard DIN rails for industrial control and power distribution.
- Part number: JPT 4-QU/JPT 4-QU-BU
- Order code: 1012.079/1012.080
Product Overview
LEIPOLE JPT 4-QU and JPT 4-QU-BU are 4-conductor screw-type feed-through terminal blocks for standard DIN rail mounting. Designed for industrial control and low-voltage distribution wiring, they provide stable multi-wire connections with reliable screw clamping. Insulation and conductive parts meet industrial standards for safe and consistent performance in industrial working environments.
Key Features & Advantages
4-conductor design for multi-wire connection
Screw connection for stable and reliable wiring
UL 94 V0 flame-retardant housing for operational safety
Compliant with IEC 60947-7-1 international standards
Compatible with NS 35/7.5, NS 35/15 and NS 32 DIN rails
Compact structure for space-saving cabinet layout
Rated 38A/800V for stable electrical performance
Typical Applications
Multi-wire wiring in industrial control cabinets
Connection of automation control circuits
Internal wiring of electrical panels and distribution boxes
Power distribution wiring for mechanical equipment
High-density wiring solutions for industrial electrical systems
| Model | JPT 4-QU/JPT 4-QU-BU |
| Certification | CE, CQC |
| Flammability Class | UL 94 V0 |
| Connection Standard | IEC 60947-7-1 |
| Zack Strip | ZB6 |
| Order Number | 1012.079/1012.080 |
| Size | T6.2×H78.7×W38 |
| Rated Current/Rated Voltage | 38A/800V |
| Cross Section | 0.5~6mm² |
| Din Rail Type | NS 35/7.5, NS 35/15, NS 32 |
