LEIPOLE JPT 4-TW/JPT 4-TW-BU 3-conductor feed-through terminal block, screw connection, DIN rail mount

LEIPOLE JPT 4-TW/JPT 4-TW-BU Feed-through Terminal Block 36A 800V Industrial Wiring

LEIPOLE JPT 4-TW/JPT 4-TW-BU 3-conductor feed-through terminal blocks with screw connection, 36A/800V rating, 0.5–6mm² wire range, UL94 V0 flame retardant housing, IEC 60947-7-1 compliant, fits standard DIN rails for industrial control and power distribution.

  • Part number: JPT 4-TW/JPT 4-TW-BU
  • Order code: 1012.076/1012.077
Add to cart

Product Overview

LEIPOLE JPT 4-TW and JPT 4-TW-BU are 3-conductor screw-type feed-through terminal blocks for standard DIN rail mounting. Designed for industrial control and low-voltage distribution wiring, they provide stable multi-wire connections with reliable screw clamping. Insulation and conductive parts meet industrial standards for safe and consistent performance in industrial working environments.

Key Features & Advantages

3-conductor design for multi-wire connection

Screw connection for stable and reliable wiring

UL 94 V0 flame-retardant housing for operational safety

Compliant with IEC 60947-7-1 international standards

Compatible with NS 35/7.5, NS 35/15 and NS 32 DIN rails

Compact structure for space-saving cabinet layout

Rated 36A/800V for stable electrical performance

Typical Applications

Multi-wire wiring in industrial control cabinets

Connection of automation control circuits

Internal wiring of electrical panels and distribution boxes

Power distribution wiring for mechanical equipment

High-density wiring solutions for industrial electrical systems

Product Attribute Value
JPT 4-TW/JPT 4-TW-BU Parameters
Model JPT 4-TW/JPT 4-TW-BU
Certification CE, CQC
Flammability Class UL 94 V0
Connection Standard IEC 60947-7-1
Zack Strip ZB6
Order Number 1012.076/1012.077
Size T6.2×H68.4×W38
Rated Current/Rated Voltage 36A/800V
Cross Section 0.5~6mm²
Din Rail Type NS 35/7.5, NS 35/15, NS 32
