LEIPOLE JPT 2.5-QU/JPT 2.5-QU-BU feed-through terminal block, screw connection, DIN rail mount, industrial wiring component

LEIPOLE JPT 2.5-QU/JPT 2.5-QU-BU Feed-through Terminal Block 24A 800V Industrial Wiring

LEIPOLE JPT 2.5-QU/JPT 2.5-QU-BU feed-through terminal blocks with screw connection, 24A/800V rating, 0.5–4mm² wire range, UL94 V0 flame retardant housing, IEC 60947-7-1 compliant, fits standard DIN rails for industrial control and power distribution use.

  • Part number: JPT 2.5-QU/JPT 2.5-QU-BU
  • Order code: 1012.062/1012.070
Add to cart

Product Overview

LEIPOLE JPT 2.5-QU and JPT 2.5-QU-BU are screw-type feed-through terminal blocks for standard DIN rail mounting. Designed for industrial control and low-voltage distribution wiring, they provide stable wire connection with reliable screw clamping. Insulation and conductive parts meet industrial standards to ensure safe and consistent operation in industrial working environments.

Key Features & Advantages

Screw connection for stable and reliable wiring

UL 94 V0 flame-retardant insulating housing for electrical safety

Compliant with IEC 60947-7-1 international standards

Compatible with NS 35/7.5, NS 35/15 and NS 32 DIN rails

Compact modular structure for efficient cabinet layout

Rated 24A/800V for stable electrical performance

Typical Applications

Wiring connection for industrial control cabinets

Automation equipment circuit connection

Internal wiring of electrical panels and distribution boxes

Power distribution for mechanical equipment systems

Industrial low-voltage distribution wiring scenarios

Product Attribute Value
JPT 2.5-QU/JPT 2.5-QU-BU Parameters
Model JPT 2.5-QU/JPT 2.5-QU-BU
Certification CE, CQC
Flammability Class UL 94 V0
Connection Standard IEC 60947-7-1
Zack Strip ZB5
Order Number 1012.062/1012.070
Size T5.2×H78.7×W38
Rated Current/Rated Voltage 24A/800V
Cross Section 0.5~4mm²
Din Rail Type NS 35/7.5, NS 35/15, NS 32
