LEIPOLE JPTTB 2.5-PV/JPTTB 2.5-PV-BU Feed-through Terminal Block 24A 800V Industrial Wiring
LEIPOLE JPTTB 2.5-PV/JPTTB 2.5-PV-BU double-level 4-conductor feed-through terminal blocks with screw connection, 24A/800V rating, 0.5–4mm² wire range, UL94 V0 flame retardant, IEC 60947-7-1 compliant, fits standard DIN rails for industrial and PV power distribution.
- Part number: JPTTB 2.5-PV/JPTTB 2.5-PV-BU
- Order code: 1012.066/1012.072
Product Overview
LEIPOLE JPTTB 2.5-PV and JPTTB 2.5-PV-BU are double-level 4-conductor screw-type feed-through terminal blocks for standard DIN rail mounting. Built for industrial control, power distribution and PV-related wiring applications, they deliver stable multi-wire connections via reliable screw clamping. Insulation and conductive parts comply with industrial standards for safe and consistent performance.
Key Features & Advantages
Double-level 4-conductor structure for high-density wiring
Screw connection for stable and durable wiring
UL 94 V0 flame-retardant insulating housing for safety
Compliant with IEC 60947-7-1 international standards
Compatible with NS 35/7.5, NS 35/15 and NS 32 DIN rails
Space-saving design for optimized cabinet layout
Rated 24A/800V for stable electrical performance
Typical Applications
High-density wiring in industrial control cabinets
Multi-circuit connection in automation systems
Internal wiring of electrical panels and distribution boxes
Wiring for photovoltaic power distribution equipment
Compact wiring solutions for industrial and renewable energy facilities
| Model | JPTTB 2.5-PV/JPTTB 2.5-PV-BU |
| Certification | CE, CQC |
| Flammability Class | UL 94 V0 |
| Connection Standard | IEC 60947-7-1 |
| Zack Strip | ZB5 |
| Order Number | 1012.066/1012.072 |
| Size | T5.2×H83.6×W48.7 |
| Rated Current/Rated Voltage | 24A/800V |
| Cross Section | 0.5~4mm² |
| Din Rail Type | NS 35/7.5, NS 35/15, NS 32 |
